1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched

1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched

  • 1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched
  • 1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched
  • 1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched
1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched
Product Details:
Place of Origin: Beijing, China
Brand Name: ADSS
Certification: CE
Model Number: FG2014
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece/pieces
Price: negotiation
Packaging Details: Alluminium alloy case for Alexandrite long pulse 1064nm Permanent Laser use
Delivery Time: 1-7days
Payment Terms: L/C D/A D/P T/T
Supply Ability: 1000 Piece/Pieces per Month
Contact Now
Detailed Product Description
Name: Yag Laser Pico Laser Tattoo Removal Machine Type: Laser
Product Name: Alexandrite Long Pulse 1064nm Permanent Laser After-sales Service Provided: Free Spare Parts, Online Support, Video Technical Support, Other
Wavelength: 1064nm Function: Hair Removal, Vascular Removal
Laser Type: Nd: Yag Laser Cooling System: Air + Water + Semiconductor Module
Feature: Hair Removal, Blood Vessels Removal, Pore Remover, Pigment Removal, Pigmentation Correctors, Skin Tightening, Whitening, Skin Rejuvenation, Dark Circles, Wrinkle Remover, Acne Treatment, Anti-Hair Removal Voltage: 110V/220V 50-60Hz
High Light:

755nm Pico Tattoo Removal Machine


532nm Pico Tattoo Removal Machine

1064 Nm 755nm 532nm Pico Q Switched Nd Yag Laser Pico Laser Tattoo Removal Machine

Name 1064 Nm 755nm 532nm Pico Q Switched Nd Yag Laser Pico Laser Tattoo Removal Machine
Wavelength 1064/532nm
Operate mode Q-switched mode & SPT mode
Beam profile Flat-top mode
Pulse width ≤6ns (Q-switched mode) 300us (SPT mode)
Pulse energy   Q-switched Q-switched SPT mode
1064nm 532nm 1064nm long pulse
Double pulse 100mJ-2600mJ 50mJ-1300mJ 100mJ-2600mJ
Single pulse 100mJ-1300mJ 50mJ-650mJ 100mJ-1300mJ
Energy calibration External & self-resoration
Spot size 2-10mm
Reprtition rate Max.10Hz(1064nm,532nm,STP mode)
Optical delivery Articulated arm
Pulse width (ns) 6ns
Aiming beam Diode 655nm(Red),brightness adjustable
Cooling system Advanced Air & Water cooling system & semiconductor cooling
Power supply AC 110V or 240V
Product Description

Tattoo removal machines are devices that use laser technology to remove unwanted tattoos from the skin. The most common type of laser used for tattoo removal is the Q-switched Nd:YAG laser.

The Q-switched Nd:YAG laser produces short pulses of high-intensity light that penetrate the skin and target the ink particles in the tattoo. The light energy is absorbed by the ink particles, causing them to break up into smaller fragments. These fragments are then eliminated by the body's immune system over time.

1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched 0


Working Theory

Nd:YAG laser energy is selectively absorbed by the deeper levels of the dermis and allows for treatment of deeper vascular lesions such as telangiectasias, hemangiomas and leg veins.The laser energy is delivered using long pulses which are converted into heat in the tissue.  The heat impacts the vasculature of the lesions. In addition, the Nd:YAG Laser can treat at a more superficial level; by heating  the subcutaneous skin (in a non-ablative manner) it stimulates neocollagenesis which improves the appearance of facial wrinkles.1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched 1




In addition to the Q-switched Nd:YAG laser, other types of lasers that can be used for tattoo removal include the Alexandrite laser and the Ruby laser. However, the Q-switched Nd:YAG laser is the most commonly used due to its effectiveness and versatility.


Overall, tattoo removal machines are effective tools for removing unwanted tattoos, but they should only be operated by trained professionals to ensure safe and effective treatment.


•Hair removal for all skin types

•Vascular Lesion

•Wrinkle Removal


•Nevus flammeus

1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched 2

Features and components of an Nd:YAG laser machine:


1. Laser medium: The Nd:YAG laser machine uses a solid-state crystal made of neodymium-doped yttrium aluminum garnet (Nd:YAG) as the laser medium. When the crystal is energized, it emits light at a specific wavelength that can be used for various medical and aesthetic applications, including tattoo removal.


2. Laser head: The laser head of an Nd:YAG laser machine contains the crystal, as well as other components such as mirrors and lenses that help focus and direct the laser beam.


3. Delivery system: The laser beam is delivered to the skin through a handpiece or fiber optic cable. The handpiece may have different tips or attachments depending on the specific application, such as a spot size adapter for tattoo removal.


4. Cooling system: Nd:YAG laser machines typically have some type of cooling system, such as a built-in air or water cooler, to prevent the laser from overheating and to minimize discomfort for the patient.


5. Controls and settings: The Nd:YAG laser machine may have various controls and settings that allow the provider to adjust the laser energy, pulse duration, and other parameters to optimize the treatment for each patient's unique needs.



1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched 3


Beijing ADSS Development Co., Ltd.(ADSS) Having been taking the technological independent innovation and improving the core hard power, ADSS has obtained the broadest sets of international certifications, including 60 design patents and 12 utility model patent certificates. ADSS owns a world-class R&D team and laboratory and uses the world's most cutting-edge technology to independently develop a series of advanced equipment systems and core power control technologies. With breakthrough innovative technologies, it quickly occupies the market and leads a new generation of medical aesthetic lasers. The core capabilities of ADSS sit in the worlds of R&D and manufacturing of medical aesthetic equipment. In years to come, ADSS will unceasingly take advantage of the rich experience and core competitiveness accumulated over these years, and promote the development by achieving innovative development strategic objectives.

 1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched 4


1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched 5

1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched 6




Packaging & Shipping


We usually ship the machine to customer by plane like DHL, UPS, TNT, FedEx .Usually it will take about 4-7 working time to come to your door .

1064nm 755nm 532nm Pico Tattoo Removal Machine Q Switched 7

Q1. Is it a reliable company?

ADSS reply: Beijing ADSS Development Co., Ltd. Is established in 2005, engaged in R&D, sales and after-sales services of aesthetic devices & medical laser equipments, even part of IT area and Real estate sector. We have a professional team integrating with optics, machinery, electricity and medicine, to keep us ahead on in this field. ADSS factory covers 160000M2. All provide ADSS is a reliable manufacturer and suppliers.


Q2: What about the delivery?

ADSS reply: we can offer the door to door services by air or by sea just depend on your actual request. Such as DHL, UPS, TNT, FEDEX… by air; and the sea transportations.


Q3: What’s the delivery time?

ADSS reply: 3-7 days.


Q4: What’s package?

ADSS reply: strong and beautiful aluminum alloy case/carton case/wooden case.


Q5: Do you have any timely technology supports?

ADSS reply: we have a professional technology supporting team for your timely services. We prepare the technical documents for you, also you can contact us by telephone, webcam, online chat (googletalk, MSN, skype, yahoo…).


Q6: What’s the payment method?



Q7: If the machines broken during the shipment, will you support us?

ADSS reply: generally our customer will purchase the insurance before shipment, avoid any money lost from rough transportation. ADSS will help you to solve the claims with the insurance companies to collect your money back in time.


Q8: do you take part in the world exhibition every year ?

ADSS Reply : yes, we took part in world-renowned exhibitions each year from 2007, such as hold in Moscow, Japan, Italy, Germany, Dubai, Australia, Mexico, Hong Kong etc…



Q9: Product series?

808nm diode laser for permanent hair removal

high intensity focused ultrasound

Fractional thermal RF

1540nm Erbium glass laser

Co2 fractional laser

Cryo fat freezing body contouring

VS+ body shaping

635nm diode laser slimming

Ultrasonic cavitation slimming

VE light (IPL+RF) system



ND YAG laser tattoo removal

PDT aesthetics
